Accessories — filter media
Versatile Filter Media Options｜High-Efficiency Oil Mist and Dust Capture｜Flexible Configuration
Bautai filter media are specifically engineered for oil mist collectors, dust collection systems, and air filtration equipment used in machine-tool and metalworking applications. A range of filter constructions and filtration grades is available to suit different machining processes, contaminant types, and equipment requirements, helping maintain consistent filtration performance and reliable system operation.
Key Features
- Multiple filter media configurations available for different machine-tool and process requirements
- Efficient capture of oil mist, airborne particulates, and fine machining dust
- Available in vertical filter cartridges, stainless-steel fiber filters, and 360° stainless-steel cylindrical filter elements
- Durable construction for continuous operation in demanding metalworking environments
- Easy installation and maintenance help reduce service time and operating costs
Applicable Equipment
Oil mist collectors, industrial dust collectors, air filtration systems, CNC machine tools, grinding machines, EDM machines, and other metalworking equipment requiring effective oil mist and particulate filtration.
Accessories — Filter Materials｜Oil Mist Collector Filter Cartridge and Industrial Filtration Consumables
Bautai provides a variety of high-efficiency filter materials and industrial filtration accessories, including vertical purification filter cartridges, stainless steel functional filter mesh, and 360° stainless steel 3D filter elements. These filter materials can be selected according to different machining conditions, oil mist concentration, dust characteristics, and equipment models.
Proper filter material selection helps improve filtration efficiency, reduce equipment clogging, extend maintenance intervals, and maintain stable operation of oil mist collectors, industrial filtration equipment, and factory air purification systems.
Vertical Purification Filter Cartridge
The vertical purification filter cartridge adopts a three-layer special material and weaving process, achieving a filtration precision of up to 5 μm and a flow capacity of 110 LPM. It effectively filters out impurities and delays filter saturation.
Depending on the operating environment and machining conditions, pollutants such as mist, oil mist, smoke, and dust may cause environmental contamination. Different material combinations can be selected, including polyester fiber, resin fiber, high-efficiency HEPA, glass fiber, or ozone O₃ treatment, to create a high-efficiency oil mist recovery purification filter cartridge with an air purification efficiency of up to 99.9%.
Stainless Steel Functional Filter Mesh
The stainless steel functional filter mesh is made with a high-strength stainless steel wire mesh structure, offering excellent corrosion resistance, high-temperature resistance, and reusability through repeated cleaning. It is ideal for filtering operations involving high concentrations of metal chips, oil contamination, and high-temperature environments.
The mesh aperture is precise and stable, effectively capturing larger particles while ensuring smooth fluid passage. This helps extend the service life of downstream filters and equipment while reducing long-term maintenance costs.
360° Stainless Steel 3D Filter Element
The 360° stainless steel 3D filter element features a full-angle three-dimensional design and multi-layer metal mesh structure, providing uniform particle capture and fine impurity filtration from all directions.
The design increases contact surface area and flow efficiency, reducing pressure drop while improving overall filtration performance. Made entirely of stainless steel, it is durable, rust-resistant, suitable for long-term operation and high-flow industrial environments, and can be cleaned and reused multiple times.
Application Scenarios
Not sure which filter material is suitable?
Please provide equipment model, machining conditions, oil mist concentration, dust characteristics, current filter photos, or filter dimensions. Bautai can assist with filter material selection and replacement recommendations.
Vertical Purification Filter Cartridge Specification
Select the suitable filter cartridge series according to machining conditions, oil mist concentration, water mist volume, smoke density, and factory air quality requirements.
L Series
Suitable for light oil mist, water mist, and light cutting environments. Filters particles down to approximately 10 μm.
S Series
Suitable for smoke, dense mist, and heavy cutting environments. Filters particles down to approximately 1 μm.
H Series
Suitable for oil mist, full oil machining, and environments with strict air quality requirements. Filters particles down to approximately 0.3 μm.
Model Selection Guide
L Series is suitable for water mist and light oil mist applications. S Series is recommended for dense mist, smoke, and heavy cutting environments. H Series is suitable for full oil machining, air-conditioned plants, or production sites with higher air quality requirements. Actual selection should be evaluated based on machining conditions, oil mist concentration, machine type, and on-site ventilation layout.
| Item | L Series | S Series | H Series |
|---|---|---|---|
| Filtration Level | Light oil mist, water mist Filters down to 10 μm | Smoke, dense mist Filters down to 1 μm | Oil mist, full oil machining Filters down to 0.3 μm |
| Application Features | Light cutting Suitable for water mist and minimal oil mist environments | Heavy cutting Suitable for dense smoke and mist environments | Full oil machining and air-conditioned plants Suitable for environments with strict air quality requirements HEPA H13 grade, 99.97% efficiency |
Not sure whether L, S, or H Series is suitable?
Please provide equipment model, machining process, coolant or oil type, mist concentration, whether full oil machining is used, and on-site environmental conditions. Bautai can assist with filter cartridge selection and replacement recommendations.
