LOD Series Dry Dust Collector｜Centralized Dust Collection & Air Purification System
Patented Vortex Separation Technology｜Energy-Efficient Performance｜Centralized Dust Collection System
The LOD Series is specifically engineered for dry dust extraction and centralized plant-wide dust collection. Featuring patented vortex separation technology, it delivers stable and efficient separation of chips, particles, and fine powders, helping minimize secondary dust dispersion and improve workplace safety.
Key Features
- Centralized dust discharge and pressure-relief housing design enhance operational safety
- Patented vortex separation technology provides stable separation performance while minimizing secondary dust dispersion
- Suitable for a wide range of process contaminants, including curled chips, particles, and fine powders
- Modular system design allows flexible expansion based on on-site dust collection requirements
- Improves powder recovery efficiency while reducing the overall energy demand of the dust collection system
Applicable Processes and Equipment
Graphite machining, fiber processing, precious-metal powder recovery, and other high-dust processes involving fine particulate materials.
System Integration
The LOD Series can serve as the central dust collection unit in a plant-wide dust management system:
Centralized Duct Collection → LOD Series → Centralized Dust Recovery or Clean-Air Discharge
This configuration is suitable for comprehensive plant-wide dust control planning, significantly improving workplace air quality, operational safety, and overall production efficiency.
LOD Series Dry Dust Collector｜Centralized Dust Collection & Air Purification System
The Bautai LOD Series dry dust collector is designed for CNC machining, grinding, dry processing, metal dust, fine powder, and industrial dust collection applications. With high-efficiency suction, precision filtration, and modular system configuration, it helps collect dust at the source, reduce airborne particles, and improve factory air quality.
The LOD Series can be configured as a single-machine dust collector, a local area dust collection system, or a centralized ducting and air purification system according to on-site conditions. It is suitable for production environments with high dust volume, multiple collection points, or factory-wide dust control requirements.
Powerful Suction Performance
Quickly increases air exchange in the working area and collects metal dust, grinding dust, dry powder, and airborne particles generated during machining, reducing dust dispersion and accumulation.
Precision Filtration System
Specially designed filtration layers effectively capture metal dust, smoke, dry particles, and fine suspended particles, helping improve factory air quality and workplace cleanliness.
Extended Maintenance Cycle
Front-stage interception and suitable filtration configuration help reduce filter load, minimize downtime for cleaning, and lower long-term maintenance cost.
Energy Saving and Sustainability
System performance can be adjusted according to site conditions to avoid over-design, helping reduce energy consumption while supporting cleaner production and sustainable factory management.
Single-Machine Application
The LOD Series can be used as a single-machine dust collector for high-dust processes, helping control local dust sources and reduce airborne dust exposure around individual machines or work areas.
System Application
The LOD Series can also be used as the main unit of a centralized dust collection system. With central ducting and multiple suction points, it helps build a complete dust control system for factory-wide dust management.
Suitable Industries and Processes
From Single-Machine Dust Collection to Factory-Wide Dust Control
The LOD Series is not only a dry dust collector but can also serve as the core unit of a factory-wide dust control system. Through high-efficiency suction, precision filtration, modular expansion, and centralized ducting design, it helps reduce dust dispersion, improve air quality, lower equipment wear, and create a safer, cleaner, and more stable production environment.
LOD Series Dry Dust Collector Specifications
Select the suitable LOD Series dry dust collector according to dust volume, machining conditions, airflow requirements, inlet configuration, and on-site installation conditions.
Light-to-Medium Dust Collection Model
Suitable for small to medium dry dust collection, single-machine use, or local dust source control.
Medium Airflow Model
Suitable for higher dust volume, multiple dust collection points, or larger machining areas.
High-Capacity Model
Suitable for larger dust volume, multiple inlets, and heavy-duty dry processing applications.
Single-Inlet Compact Model
Suitable for single-machine dust collection or installation areas with limited space.
Model Selection Guide
LOD-45 and LOD-1000 are suitable for compact or single-machine applications. LOD-80 is suitable for higher dust volume and larger machining areas. LOD-120 is recommended for multiple inlets, heavy-duty processes, or centralized dust collection planning. Actual selection should be evaluated based on dust type, airflow requirement, duct layout, and site conditions.
| Item | LOD-45 | LOD-80 | LOD-120 | LOD-1000 |
|---|---|---|---|---|
| Power | 2 HP 1.5 kW | 3 HP 2.25 kW | 5 HP 3.7 kW | 2 HP 1.5 kW |
| Frequency | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz |
| Voltage | 3φ 220 / 380 V | 3φ 220 / 380 V | 3φ 220 / 380 V | 3φ 220 / 380 V |
| Inlet Diameter | 200 mm × 2 pcs | 200 mm × 2 pcs | 200 mm × 3 pcs | 150 mm × 1 pc |
| Speed | 1750 RPM | 1750 RPM | 1750 RPM | 1750 RPM |
| Noise Level | 75 dB | 75 dB | 75 dB | 75 dB |
| Dimensions | 800L × 900W × 2375H mm | 1100L × 1300W × 2550H mm | 1150L × 1800W × 2700H mm | 650L × 650W × 1900H mm |
Not sure which LOD model is suitable?
Please provide dust type, machining process, number of dust collection points, duct layout, required airflow, and site photos. Bautai can assist with initial dry dust collector model selection and system planning.
